Weiand Intake Manifold 8501WND; Speed Warrior Dual Plane 1500 to 6700 Satin Aluminum for 1955 to 1986 Chevy 262 to 400
$339.77
$449.95 On Sale
Save 24%
This item is not eligible for our Free Freight program because either this part type is excluded or its price is already at our lowest. However, it will still count toward the total when you purchase other items that do qualify for Free Freight.
See our shipping policy for more details.
Details
- Port Size 1.92 in. Height x 1.16 in. Width
- 1500-6700 RPM Power Band
- Square Bore Carburetor Flange
- Isolated Runners To Reduce Intake Charge Heating
- Promotes Airflow Between Hot Engine/Intake Plenum
- High Rise/Dual Plane Design
- Precision CNC Machining
- Permanent Mold Casting
- Height Front 4.19 in.
- Rear 5.27 in.
- Promotes Airflow Between Hot Engine/Intake Plenum
- High Rise/Dual Plane Design
- Precision CNC Machining
- Permanent Mold Casting
- Height Front 4.19 in.
- Rear 5.27 in.
Product Description
The Weiand Speed Warrior features long, separated runners for bottom-end and mid-range power, plus a special runner design and larger plenum to flow the air needed for high-RPM horsepower. All of this usable power makes this intake perfect for your street and strip hot rod! * Utilizes late model alternator an A/C bracket mounting provisions. Has additional vacuum tap off of runner. Recommended intake manifold gasket - Mr Gasket #'s 5821 or 101G
Specifications
- Intake Manifold Series:
- Speed Warrior
- Year:
- 1955 to 1986
- Make:
- Chevy
- Engine:
- 262 to 400
- Deck Height:
- 9.025 in.
- Port Style:
- Rectangular
- Intake Style:
- Dual Plane
- Carburetor or Throttle Body Flange:
- 4150 Square Flange
- RPM Range:
- 1500 to 6700
- EGR or Non-EGR:
- Non EGR
- Material:
- Aluminum
- Finish:
- Satin
- Includes Gaskets:
- No
- Front Height:
- 4.190 in.
- Fuel System Type:
- Carbureted
- Requires Aftermarket Fuel Rails:
- No
- Includes Fuel Rails:
- No
- Rear Height:
- 5.270 in.
- Quantity:
- Sold As Each
