SRP Pistons (Sportsman Racing Products) Piston Set 138091; 4.060 in. -5.00 cc Flat Top (2V) for Chevy 350
$543.82
Part #: 138091
Brand: SRP Pistons (Sportsman Racing Products)
Estimated Ship Date: 6/21/2025 (From manufacturer)
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Details
- Ideal for oval track to street/strip applications.
- Forged from 4032 low expansion high silicon aluminum alloy heat treated to SRP specifications
- Forced Pin Oiler for increased wrist pin lubrication
- Pin fitting, and double spiro locks included
- 927-2750-150 wall wrist pin (130 grams) included
- CNC Machined ring grooves accept 1/16, 1/16, 3/16 rings (Rings Sold Separately)
- Recommended ring setS100S8-4060-5
- 927-2750-150 wall wrist pin (130 grams) included
- CNC Machined ring grooves accept 1/16, 1/16, 3/16 rings (Rings Sold Separately)
- Recommended ring setS100S8-4060-5
Product Description
All Srp Flat Top Pistons are forged from 4032 low expansion high silicon alloy that is heat treated to SRP specifications. Forced pin oiler for increased wrist pin lubrication. Includes double spiro locks wrist pins. Cnc machined grooves accept 1/16, 1/16, 3/16 rings Priced per set of 8, please call to order individual pistons.
Specifications
- Make:
- Chevy
- Engine:
- 350
- Bore:
- 4.060 in.
- Stroke:
- 3.750 in.
- Rod Length:
- 5.700 in.
- Compression Height:
- 1.425 in.
- Crown Volume:
- -5.00 cc Flat Top (2V)
- Weight:
- 492 g
- Cylinder Head Volume to Calculate Compression Ratio:
- 64.00 cc
- Compression Ratio:
- 11.1
- Pin Diameter:
- 0.927 in.
- Piston Material:
- Forged 4032 Alloy
- Ring Lands:
- 1/16, 1/16, 3/16 in.
- Wrist Pin Fitment:
- Floating
- Rings Included:
- No
- Quantity:
- Sold As Set (8/pkg)
