Sniper Fuel Injection System 550-871K; Sniper EFI Stealth 650 HP Throttle Body 870 CFM Black Aluminum
$1,959.95
Need It Faster?
We recommend this alternative part:
Details
- Bolt on 4150 Flange Carburetor Replacement
- Throttle body mounted ECU - no extra boxes to mount
- Supports up to 650hp with Four 100 Lb/Hr Injectors!
- All of the wiring exits below the rear fuel injector cover, for a completely stealth installation.
- Timed spark part for vacuum advanced distributors located under the front fuel bowl, for easy access to the distributor.
- Air entry is machined to fit most stock style air cleaners with air cleaner locator provisions.
- Only 4 Wiring Connections Required! (Battery +, Battery - , Switched Ignition & RPM)
- External fuel pressure regulator required, set to a base pressure of 58.5 PSI, such as 12-886.
- Integrated ignition timing control
- High Resolution Full Color Touchscreen for Initial Setup, Tuning, and Gauge Displays
- Simple Calibration Wizard (answer a few questions about your engine and it creates the base map, then starts tuning on its own!) - NO laptop required!
- Self-tuning ECU means you don’t have to be a computer/tuning wiz to have EFI!
- The included Genuine Bosch LSU 4.9 Wideband Oxygen Sensor provides real-time Fuel Map Learn!
- OEM Style TPS/IAC and Fuel Pressure regulator, for years of dependable service.
- Included clamp-on oxygen sensor kit for 2.25" exhaust ensures a leak free oxygen sensor installation, with Stainless Steel T-Bolt clamps and a Stainless Steel (Weldable) oxygen sensor flange
- Available in 3 finishes: Shiny, Black and coming soon, Gold
- Timed spark part for vacuum advanced distributors located under the front fuel bowl, for easy access to the distributor.
- Air entry is machined to fit most stock style air cleaners with air cleaner locator provisions.
- Only 4 Wiring Connections Required! (Battery +, Battery - , Switched Ignition & RPM)
- External fuel pressure regulator required, set to a base pressure of 58.5 PSI, such as 12-886.
- Integrated ignition timing control
- High Resolution Full Color Touchscreen for Initial Setup, Tuning, and Gauge Displays
- Simple Calibration Wizard (answer a few questions about your engine and it creates the base map, then starts tuning on its own!) - NO laptop required!
- Self-tuning ECU means you don’t have to be a computer/tuning wiz to have EFI!
- The included Genuine Bosch LSU 4.9 Wideband Oxygen Sensor provides real-time Fuel Map Learn!
- OEM Style TPS/IAC and Fuel Pressure regulator, for years of dependable service.
- Included clamp-on oxygen sensor kit for 2.25" exhaust ensures a leak free oxygen sensor installation, with Stainless Steel T-Bolt clamps and a Stainless Steel (Weldable) oxygen sensor flange
- Available in 3 finishes: Shiny, Black and coming soon, Gold
Product Description
Supports Up To 650HP - 3.5 in. Handheld Monitor - Carburetor Styling - Return Fuel System
Specifications
- Fuel Injection System Series:
- Sniper EFI Stealth
- Injection Style:
- Throttle Body
- Supported Horsepower:
- 650 HP
- Includes Intake Manifold:
- No
- Includes Throttle Body:
- Yes
- Throttle Body Mounting Flange:
- Square
- Throttle Body CFM:
- 870 CFM
- Throttle Body Material:
- Aluminum
- Throttle Body Finish:
- Black
- Includes Fuel Rails:
- No
- Injector Flow Rate:
- 100 lbs/hr.
- Includes Hand-Held Calibration Module:
- Yes
- Includes ECM:
- Yes
- Includes Fuel Pump:
- Yes
- Includes Fuel Pressure Regulator:
- Yes
- Sensors Included:
- O2, MAP, IAT, TPS
- Quantity:
- Sold As Kit
