Sniper Fuel Injection System 550-510-3XR; Sniper 2 with Drop-In Pump 650 HP Throttle Body 800 cfm Shiny Aluminum
$1,699.99
$2,099.95 On Sale
Save 19%
This item is not eligible for our Free Freight program because either this part type is excluded or its price is already at our lowest. However, it will still count toward the total when you purchase other items that do qualify for Free Freight.
See our shipping policy for more details.
Details
- Main Features
- All new design – the P/N 1 EFI Conversion just got better!
- Only four wiring connections required: Battery+, Battery-, Switched Ignition, and RPM
- Calibration wizard only requires that you answer a few simple questions about your engine to create a base map and begin self-tuning – No laptop required
- Supports up to 650horsepower naturally aspirated or 575horsepower on boost with four 100 lbs/hr injectors
- (NEW) Next generation ECU features improved RF noise and interference resistance (stands up to old car wiring, noisy alternators, faulty plug wires)
- (NEW) Redesigned throttle shaft and plate geometry for a smoother throttle feel
- All new design &ndash
- the P/N 1 EFI Conversion just got better!
- Sniper 2 is compatible with the complete Sniper EFI Ecosystem that includes plug-n-play Hyperspark Ignition systems (coil, ignition box and distributor), fuel systems (fuel lines, fuel pump hangers), multiple displays and more
- (NEW) Main harness includes plug-and-play HyperSpark distributor support, for integrated timing control, making your ignition setup hassle free
- (NEW) &ldquo
- Hidden Harness" wiring harnesses exits from the rear of throttle body for a clean appearance
- Additional Features
- (NEW) Optional Power Distribution Module (PDM) further simplifies wiring, especially when used in conjunction with an ignition system
- Available with fuel system kits: a complete fuel system consisting of: 20 ft. of 3/8 in. Vapor Guard Fuel Hose, Fuel Pump, fuel pressure regulator, filters, necessary hardware, and bulkhead fitting to return fuel into the tank
- (NEW) Integrated transmission kick down provisions for GM TH350/400, 200-4R/700R4 and Ford C4/C6 applications
- (NEW) “Hidden Harness” wiring harnesses exits from the rear of throttle body for a clean appearance
- (NEW) Inputs and outputs consist of: 2x Ground Inputs, 2x Ground Outputs, 1x TPS output (0-5v), and 1x Tach Output
- Calibration wizard only requires that you answer a few simple questions about your engine to create a base map and begin self-tuning &ndash
- No laptop required
- (NEW) Onboard contactless magnetic TPS sensor ensures an accurate TPS reading
- Supports up to 650horsepower naturally aspirated or 575horsepower on boost with four 100 lbs/hr injectors
- (NEW) Next generation ECU features improved RF noise and interference resistance (stands up to old car wiring, noisy alternators, faulty plug wires)
- (NEW) Redesigned throttle shaft and plate geometry for a smoother throttle feel
- All new design &ndash
- the P/N 1 EFI Conversion just got better!
- Sniper 2 is compatible with the complete Sniper EFI Ecosystem that includes plug-n-play Hyperspark Ignition systems (coil, ignition box and distributor), fuel systems (fuel lines, fuel pump hangers), multiple displays and more
- (NEW) Main harness includes plug-and-play HyperSpark distributor support, for integrated timing control, making your ignition setup hassle free
- (NEW) &ldquo
- Hidden Harness" wiring harnesses exits from the rear of throttle body for a clean appearance
- Additional Features
- (NEW) Optional Power Distribution Module (PDM) further simplifies wiring, especially when used in conjunction with an ignition system
- Available with fuel system kits: a complete fuel system consisting of: 20 ft. of 3/8 in. Vapor Guard Fuel Hose, Fuel Pump, fuel pressure regulator, filters, necessary hardware, and bulkhead fitting to return fuel into the tank
- (NEW) Integrated transmission kick down provisions for GM TH350/400, 200-4R/700R4 and Ford C4/C6 applications
- (NEW) “Hidden Harness” wiring harnesses exits from the rear of throttle body for a clean appearance
- (NEW) Inputs and outputs consist of: 2x Ground Inputs, 2x Ground Outputs, 1x TPS output (0-5v), and 1x Tach Output
- Calibration wizard only requires that you answer a few simple questions about your engine to create a base map and begin self-tuning &ndash
- No laptop required
- (NEW) Onboard contactless magnetic TPS sensor ensures an accurate TPS reading
Product Description
Make your classic drive like a modern fuel-injected vehicle, including easy cold starts, smooth drivability, and improved fuel economy! Sniper 2 is designed to be installed at home in your garage with limited tools and the support of Holley's comprehensive installation manual and videos. The user-friendly setup wizard allows you to answer a few simple questions about your engine and the system will begin self-tuning with no laptop or tuning experience required.
Specifications
- Fuel Injection System Series:
- Sniper 2 with Drop-In Pump
- Injection Style:
- Throttle Body
- Supported Horsepower:
- 650 HP
- Includes Intake Manifold:
- No
- Includes Throttle Body:
- Yes
- Throttle Body Mounting Flange:
- Square Flange 4 Barrel
- Throttle Body CFM:
- 800 cfm
- Throttle Body Material:
- Aluminum
- Throttle Body Finish:
- Shiny
- Includes Fuel Rails:
- No
- Number of Injectors Included:
- 4
- Injector Flow Rate:
- 100 lbs/hr.
- Includes Hand-Held Calibration Module:
- Yes
- Includes ECM:
- Yes
- Includes Fuel Pump:
- Yes
- Includes Fuel Pressure Regulator:
- Yes
- Sensors Included:
- MAP, IAT, TPS, IAC, O2
- Quantity:
- Sold as Kit
