MSD Ignition Coil 8225; Blaster HEI Coil Black 42000 Volt In Cap for 1974 to 1995 GM
$122.95
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Details
- Direct performance replacement for GM HEI coil-in-cap dist.
- 70:1 Turns Ratio
- Lower Primary Resistance Produces High Voltage Output
- Full Power Sparks To 9000 Rpm with PN[83647] MSD HEI Module
- Recommended For Use with MSD HEI Module PN[83647]
- CARB E.O. Approved
- Recommended For Use with MSD HEI Module PN[83647]
- CARB E.O. Approved
Product Description
HEI owners now have a choice to replace their stock coil with the MSD high energy unitized coil for GM HEI distributors. This coil is a direct replacement of the stock coil and offers increased spark energy when used with the MSD HEI module, PN 83645. The coil features special low inductance, high temperature windings which charge faster to give you increased spark energy at higher rpm. The premium epoxy filled construction is designed to withstand harsh race applications as well as the wear and tear that daily usage dishes out, and still deliver more spark energy to the spark plugs.
Specifications
- Ignition Coil Series:
- Blaster HEI Coil
- Year:
- 1974 to 1995
- Make:
- GM
- Coil Type:
- In Cap
- Maximum Voltage:
- 42000 Volt
- Primary Resistance:
- 0.310 Ohms
- Secondary Resistance:
- 9.2K Ohms
- Height:
- 4.000 in.
- Finish:
- Black
- Internal Construction:
- Epoxy Filled
- Primary Inductance:
- 3.50 mH
- Turns Ratio:
- 70:1
- Includes Mounting Bracket:
- No
- Includes Ballast Resistor:
- No
- Includes Hardware:
- No
- Quantity:
- Sold As Each
