Manley Connecting Rods 14054R-8; H-Beam 6.000 in. Bushed for Chevy 262 to 400
$816.77
$902.98 On Sale
Save 10%
This item is not eligible for our Free Freight program because either this part type is excluded or its price is already at our lowest. However, it will still count toward the total when you purchase other items that do qualify for Free Freight.
See our shipping policy for more details.
Details
- Exacting Tolerances: Our H-Beam rods are finished to exacting tolerances to ensure precision and performance.
- Attention to Detail: Every aspect from final hone size to thread detail bend and twist is treated with utmost seriousness to deliver connecting rods of the highest quality.
- Exceptional Performance: Manley's H-Beam rods are designed to outperform others on the market giving you a competitive advantage on the track.
- Flexible Bolt Options: Tailor your connecting rods to your specific requirements with a choice of ARP 8740 or ARP 2000 bolts.
Product Description
When it comes to H-Beam connecting rods, not all are created equal. Manley's H-Beam Series stands out as a superior choice, offering exceptional quality at an economical price point. These connecting rods are meticulously crafted to meet the same high-quality standards as our renowned Sportsmaster? and Pro Series rods.
Specifications
- Make:
- Chevy
- Engine:
- 262 to 400
- Beam Style:
- H-Beam
- Rod Length:
- 6.000 in.
- Material:
- Forged 4340 Steel
- Weight:
- 640 g
- Rod Journal Diameter:
- 2.100 in.
- Wrist Pin Diameter:
- 0.927 in.
- Wrist Pin Style:
- Bushed
- Rod Bolt Style:
- Cap Screw
- Rod Bolt Diameter:
- 7/16 in.
- Rod Bolt Material:
- ARP 2000
- Stroker Clearanced:
- No
- Rated Horsepower:
- 900 HP
- Maximum RPM:
- 8,000 RPM
- Connecting Rod Finish:
- Shot Peened
- Big End Bore:
- 2.225 in.
- Notes:
- Large Journal
- Quantity:
- Sold As Set (8/pkg)
