Mallory Ignition Control Box 690; HyFire Capacitive Discharge 95 mJ Black
$247.55
Part #: 690
Brand: Mallory
UPC: 085132006908
Estimated Ship Date: This part is unavailable with no ETA
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Details
- Modern Capacitive Discharge Ignition Technology
- Retro Design For Classic Good Looks
- Connects Easily To Points/Amplifiers/Magnetic Pickup Distributors
- Adjustable Rev Limiter For Overrev Protection
- Multiple Sparks At Low RPM
- Improved Starting/Clean Idle/Snappy Throttle Response
- Multiple Sparks At Low RPM
- Improved Starting/Clean Idle/Snappy Throttle Response
Product Description
A modern twist on a familiar name in ignition performance is back! The Mallory HyFire needs no introduction. Packed inside the retro case are modern electronics ready to deliver a powerful ignition punch. The HyFire is a capacitive discharge ignition that supplies multiple sparks at low RPM's for a clean idle and quick throttle response. Since the HyFire provides powerful spark through redline, a built in adjustable rev limiter will help tame your beast in case of a missed shift or driveline failure. The rev limiter is adjustable in 100 RPM increments with easily adjustable rotary dials.
Specifications
- Ignition Control Box Series:
- HyFire
- Circuitry:
- Capacitive Discharge
- Programmable:
- Non Programmable
- Spark Energy:
- 95 mJ
- Spark Duration:
- 20 deg.
- Primary Voltage:
- 435 Volt
- Secondary Voltage:
- 43,000 Volt
- Maximum RPM:
- 15,000 RPM
- Rev Limiter:
- Yes
- Case Finish:
- Black
