Flo-Tek Cylinder Head Assembly 1200-SRAC-505A; 200cc Aluminum 64cc for Chevy 262 to 400
$599.99
$669.00 On Sale
Save 10%
This item is not eligible for our Free Freight program because either this part type is excluded or its price is already at our lowest. However, it will still count toward the total when you purchase other items that do qualify for Free Freight.
See our shipping policy for more details.
Product Description
The features for the FLOTEK 200cc include state of the art casting, versatile 200 cc intake ports that are specifically designed for outstanding versatility, 64 cc combustion chamber. These are the most affordable high quality aluminum cylinder heads on the market. The FLOTEK Performance Cylinder Heads series are a line of heads designed by Tri-State Cylinder Head for maximum out-of-the-box horsepower. Standard features are aluminum alloy, phosphorous bronze valve guides, high nickel valve seats, ends milled and drilled for accessories, offered in solid or hydraulic.
Specifications
- Make:
- Chevy
- Engine:
- 262 to 400
- Material:
- Aluminum
- Combustion Chambers:
- 64cc
- Intake Valve Diameter:
- 2.020 in.
- Exhaust Valve Diameter:
- 1.600 in.
- Spark Plug Angle:
- Angled
- Intake Runners:
- 200cc
- Exhaust Runners:
- 78cc
- Port Style:
- Rectangular
- Cam Type Recommended:
- Mechanical Roller
- Max Valve Lift:
- 0.650 in.
- Valve Spring OD:
- 1.550 in.
- Closed Spring Pressure:
- 230 lbs. @ 1.900 in.
- Open Spring Pressure:
- 600 lbs. @ 1.250 in.
- Spring Rate:
- 569.2 lbs/in.
- Coil Bind:
- 1.150 in.
- Valve Spring Retainer Material:
- Chromoly
- Quantity:
- Sold As Each
