Edelbrock Intake Manifold 2904; Victor Jr. Single Plane 3500 to 7500 Satin Aluminum for Chevy 396 to 454
$419.36
$465.95
Save 10%
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Product Description
Edelbrock part #2904 Victor Jr. 454-O intake manifold is designed for competition 396-502 big-block Chevys with large oval-port heads (1975 & earlier). Features include extended runner dividers, smaller plenum chambers and unique runner design for better 60 foot times and max power from 3500 to 7500 rpm. This manifold is especially suited to 502 c.i.d. and smaller competition engines. This intake manifold is a single plane 4150 flange competition manifold designed to fit standard deck blocks from 1965 to present. It is designed to be matched with our Edelbrock/Musi Victor 24-degree Pro-Port CNC heads #61419 or #61409 for 950+ hp out-of-the-box potential!
Specifications
- Intake Manifold Series:
- Victor Jr.
- Make:
- Chevy
- Engine:
- 396 to 454
- Deck Height:
- 9.800 in.
- Port Style:
- Oval
- Intake Style:
- Single Plane
- Carburetor or Throttle Body Flange:
- 4150 Square Flange
- RPM Range:
- 3500 to 7500
- EGR or Non-EGR:
- Non EGR
- Material:
- Aluminum
- Finish:
- Satin
- Includes Gaskets:
- No
- Front Height:
- 5.900 in.
- Fuel System Type:
- Carbureted
- Requires Aftermarket Fuel Rails:
- No
- Includes Fuel Rails:
- No
- Rear Height:
- 5.900 in.
- Quantity:
- Sold As Each
