Photo for Diamond Pistons Piston and Rings Kit 70107-8; 4.468 in. -0.60 cc Flat Top for Mercury 565EFI

Diamond Pistons Piston and Rings Kit 70107-8; 4.468 in. -0.60 cc Flat Top for Mercury 565EFI

$1,675.49

Part #: 70107-8

Brand: Diamond Pistons

UPC: 193564421159

Estimated Ship Date: This part is temporarily unavailable with no ETA

Specifications

This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.

Details

  • Pin Fitted
  • Moly Coated Skirts
  • 3D Dome & Pockets
  • Inboard Forging
  • Pins, Lock's & Support Rails (if required) included

Specifications

Make:
Mercury
Engine:
565EFI
Bore:
4.468 in.
Stroke:
4.250 in.
Rod Length:
6.385 in.
Compression Height:
1.255 in.
Crown Volume:
-0.60 cc Flat Top
Pin Diameter:
0.984 in.
Piston Material:
Forged
Ring Lands:
1.5, 1.5, 4.0 mm
Top Ring Type:
Hardened Ductile Iron
Second Ring Type:
Hardened Ductile Iron Napier
Oil Ring Tension:
High Tension
Quantity:
Sold As Kit (8/pkg)
