Derale Electric Fan 16913; High Output Single RAD High: 2100; Low: 1500 CFM Electric 14.000 in.
$186.90
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Details
- 14" High Output Single RAD Pusher/Puller Fan with Standard Mount Kit
Product Description
A very popular primary cooling fan, this 14" High Output Single RAD fan is a self-shrouded, symmetrical design with four molded mounting points. Motivated by a 2-speed 265 watt Bosch motor driving 11 patented skewed blades, it can be used as a pusher with the supplied hardware kit. Fan can also be used as puller by combining with a custom built shroud. Moves up to 2100 CFM while drawing up to 22 amps.
Specifications
- Electric Fan Series:
- High Output Single RAD
- Fan Type:
- Electric
- Maximum CFM:
- High: 2100; Low: 1500 CFM
- Fan Diameter:
- 14.000 in.
- Blade Finish:
- Black
- Amp Draw:
- High: 22.0 Amps; Low: 16.2 Amps
- Shroud Height:
- 14.500 in.
- Shroud Width:
- 14.500 in.
- Shroud Thickness:
- 1.625 in.
- Shroud Material:
- Plastic
- Shroud Color:
- Black
- Includes Mounting Hardware:
- Yes
- Includes Wiring Harness:
- No
- Assembly Depth:
- 2.625 in.
- Quantity:
- Sold As Kit
