Derale Electric Fan 16016; Tornado 2175 CFM Electric 16.000 in. Skewed
$211.15
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Need It Faster?
We recommend this alternative part:
Details
- 16" Tornado Electric Fan & 180°F Dual Probe Fan Controller Kit
Product Description
Our top of the line 16" reversible Tornado fan uses 8 skewed blades, producing a healthy 2175 CFM at 0 static pressure, drawing only 18.4 amps. Kit includes a high quality single stage fan controller with preset 180°F-on and 165°F-off temperature controls and includes both a push-in radiator probe and a 3/8" NPT brass water jacket probe, plus all necessary installation hardware. Made in the USA.
Specifications
- Electric Fan Series:
- Tornado
- Fan Type:
- Electric
- Maximum CFM:
- 2175 CFM
- Fan Diameter:
- 16.000 in.
- Blade Type:
- Skewed
- Fan Directon:
- Reversible, Puller by Default
- Blade Finish:
- Black
- Blade Material:
- Plastic
- Amp Draw:
- 18.4 Amp
- Shroud Height:
- 15.500 in.
- Shroud Width:
- 16.750 in.
- Shroud Thickness:
- 1.750 in.
- Shroud Material:
- Plastic
- Shroud Color:
- Black
- Includes Mounting Hardware:
- Yes
- Includes Wiring Harness:
- Yes
- Assembly Depth:
- 3.875 in.
- Includes Air Conditioning Relay:
- No
- Notes:
- Puller (Reversible)
- Quantity:
- Sold As Kit
