Competition Engineering Suspension Ladder Bar C2005; Ladder Link Ladder Bars

$483.99

Part #: C2005

Brand: Competition Engineering

UPC: 084663020056

Estimated Ship Date: This part is unavailable with no ETA

Specifications Recommended

This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.

Details

Competition Engineering's Ladder Link Double Adjustable Ladder Bar™ is designed so that the user can adjust preload and pinion angle without removal of Part No. C2005. This is accomplished by adjusting the front rod end and/or rear rod ends of the Ladder Bar itself. Includes two unique one-piece brackets which get welded to the rear end housing, cutting down on installation time and errors.
Comes with two Ladder Bars, NHRA Approved Safety Brackets and hardware
Adjuster allows quick on-vehicle preload adjustments for changing track conditions
Contains two one piece 3/16 steel mounting brackets make installation easier
33-1/2" overall length
1 dia. x .156 wall DOM steel tube construction
Black powder coat finish
Rod ends, Front - Chrome Moly Spherical, Rear Fully Machined Solid
For use with 3" O.D. Axle Tubes
Welding required

Product Description

Ladder Link Ladder Bar, The dual pivoting adjustable lower link on the Ladder Link allows the racer to fine tune the suspension without removing the bar from the car. By simply loosening the jam nuts on the link and rotating it in the desired direction, both pinion angle and chassis preload can be changed. Unlike other so-called adjustable Ladder Bars, the Ladder Link does create a binding situation when it is adjusted. The other bars with non-pivoting adjusters change the center to center mounting distance on the rear of the bar. Pivoting lower adjusters eliminate the bind found in competitor' bars. Adjuster allows quick on-vehicle preload adjustments, 1" dia. x .156" wall DOM steel tube construction, forged solid rear rod ends, welding required, 33-1/2" overall lenght, High quality spherical front rod ends, Black powder coat finish

Specifications

Suspension Ladder Bar Series:
Ladder Link Ladder Bars: Mounting Style:
Weld On: Length:
33.500 in.: Adjustable:
Yes: Welding Required:
Yes: Rod Ends Included:
Yes: Safety Brackets Included:
Yes: Gussets Included:
Yes: Tubing Diameter:
1.000 in.: Hardware Included:
Yes: Crossmember Included:
No: Material:
DOM Steel Tube 0.156 in. Wall: Finish:
Black Powdercoat: Quantity:
Sold As Pair
