COMP Cams Valve Spring Set 941-16; Race Sportsman 454 lbs/in. Single Spring 1.269 in.
$225.95
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Product Description
Single Outer Valve Springs from COMP Cams allow you to build the perfect spring assembly for your application. The valve spring creation process is far more involved than most people realize. Selecting the right metal stock and creating the best design is not done by chance. COMP Cams has developed a process that creates the highest quality valve spring available. The result is a product that meets and exceeds the expectations of today's engine builders and racers.
Specifications
- Valve Spring Set Series:
- Race Sportsman
- Number Of Coils:
- Single Spring
- Damper Spring:
- Yes
- Overall Diameter:
- 1.269 in.
- Inside Diameter:
- 0.876 in.
- Spring Height:
- 1.750 in.
- Seat Pressure:
- 130 lbs. @ 1.750 in.
- Open Pressure:
- 359 lbs. @ 1.250 in.
- Coil Bind:
- 1.100 in.
- Spring Rate (lbs./in.):
- 454 lbs/in.
- Max Lift:
- 0.575 in.
- Material:
- Chrome Silicon
- Designed for Cam Type(s):
- Hydraulic Roller
- Quantity:
- Sold As Set (16/pkg)
