COMP Cams Camshaft 12-225-4; Magnum 3000 to 7000 RPM 0.555 in. 0.555 in. Mechanical Flat Tappet for Chevy 262 to 400
$260.95
Part #: 12-225-4
Brand: COMP Cams
UPC: 036584540069
Estimated Ship Date: 5/31/2025 (From manufacturer)
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Details
- Great high RPM power
- Easy on valve train parts
- Can be used with mild ratio rocker arms and traditional performance valve springs
- Best with aftermarket converter and 9.5:1+ compression
Product Description
An older member of the COMP Cams grind family, the Magnum series of camshafts offers excellent performance gains over stock without the added wear and tear associated with more aggressive camshafts. Ideal for use with higher compression ratio engines that need to bleed off compression, the magnum series performs its best when static compression is 9.5:1+ and with an aftermarket higher stall torque converter. Delivering excellent high RPM power, while not needlessly abusing valve train parts, the Magnum grind family is the perfect choice for performance engines equipped with mild ratio rocker arms and traditional performance valve springs.
Specifications
- Camshaft Series:
- Magnum
- Make:
- Chevy
- Engine:
- 262 to 400
- Camshaft Type:
- Mechanical Flat Tappet
- RPM Range:
- 3000 to 7000 RPM
- Intake Valve Lift:
- 0.555 in.
- Exhaust Valve Lift:
- 0.555 in.
- Advertised Intake Duration:
- 306 deg.
- Advertised Exhaust Duration:
- 306 deg.
- Intake Duration @ .050":
- 260 deg.
- Exhaust Duration @ .050":
- 260 deg.
- Lobe Separation:
- 110 deg.
- Cam Gear Attachment:
- 3 Bolt
- Camshaft Material:
- Cast Iron
- Camshaft Grind Number:
- 306S
- Usage:
- Street, Strip
- Requires Aftermarket Valve Springs:
- Yes
- Notes:
- Includes assembly lubricant
- Quantity:
- Sold As Each
