Centerforce Clutch and Flywheel Kit KDF512009; Cast Iron

$309.95

Part #: KDF512009

Brand: Centerforce

Estimated Ship Date: This part is temporarily unavailable with no ETA

This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.

Details

  • 7.500" Diameter

Product Description

The Centerforce(R) Dual Friction(R) Clutch Series is a performance matched pressure plate & disc combination featuring the patented Centerforce centrifugal weight system (where applicable) and specialized machining processes to provide a performance clutch that offers exceptional street characteristics, while offering outstanding holding-capacity and durability. Furthermore, the Centerforce Dual Friction disc has an organic full facing on one side for longevity and an organic segmented facing on the other side providing increased holding capacity. Some applications have the organic segmented facings of both sides. The Dual Friction clutch is engineered for those who are looking for the ultimate in street/strip holding power and performance without sacrificing pedal effort and driver control. While the Dual Friction has been engineered primarily as a street clutch it can be used in mild competition applications.

Specifications

Pressure Plate Material:
Cast Iron
With Centrifugal Weights:
Yes
Disc Style:
Full Face, Segmented Face, Sprung Hub
Disc Diameter:
7 1/2 in.
Disc Material:
Organic
Input Splines:
20 Spline
Input Shaft Diameter:
0.875 in.
Includes Throwout Bearing:
Yes
Torque Capacity:
179 lbs/ft.

Videos

Tech Resources

  • KDF512009.PDF
