Canton Oil Pan 15-276; Road Race Wet Sump 6.5 Quart Clear Zinc Plated for Chevy LS
$448.00
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Details
- 6.5 qt System Capacity
- 4.25" Stroke Clearance
- Diamond Shape Trap Door Baffle
- Bolt in Slosh Baffle
- 20 mm bung for low oil warning sensor (22-405 required if not used)
- Provision for our 1/4 NPT pan mounted dipstick
- Magnetic Drain Plug
- 20 mm bung for low oil warning sensor (22-405 required if not used)
- Provision for our 1/4 NPT pan mounted dipstick
- Magnetic Drain Plug
Product Description
Canton?s new 15-276 front sump road race/drift car oil pan is designed for GM LS1/LS6 powered cars that require a shallow front sump oil pan. This pan is designed to use the GM pickup part number #12572654 from the 04-06 GTO. It?s diamond shaped baffle with 4 trap doors and removable windage/anti-slosh baffle provide the best oil control under demanding street and track conditions. With provisions for a pan mounted dipstick and 20 mm oil level sensor along with a 6.5 quart system oil capacity.
Specifications
- Oil Pan Series:
- Road Race
- Make:
- Chevy
- Engine:
- LS
- Pan Style:
- Wet Sump
- Capacity:
- 6.5 Quart
- Depth:
- 5.625 in.
- Material:
- Steel
- Finish:
- Clear Zinc Plated
- Kick Out:
- Yes
- Sump Location:
- Front
- Baffled:
- Yes
- Includes Pickup:
- No
- Standard Pickup Part Number:
- GM 12572654
- Includes Windage Tray:
- No
- Includes Crank Scraper:
- No
- Includes Gasket:
- No
- Includes Hardware:
- No
- Notes:
- Has 20mm provision for oil temp sensor. Must use 22-630 or 22-631
- Quantity:
- Sold As Each
