Air Flow Research Cylinder Head Assembly 1420; Renegade Street 185.00 cc Aluminum 72 cc for Ford 289 to 351W
$1,999.99
$2,328.90 On Sale
Save 14%
See our shipping policy for more details.
Product Description
AFR's 185cc "Street" cylinder heads feature 100% CNC ported intake, exhaust & chambers, A356 aluminum castings and high quality components throughout. Recommended for engines from 302-393 cubic inches, operating up to 6000-06500 RPM. Legal for 1995 and older emissions controlled vehicles under CARB EO #D-250-03. Not compatible with OEM pistons. AFR heads are available bare (without parts), call our tech line for details.
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Specifications
- Cylinder Head Assembly Series:
- Renegade Street
- Make:
- Ford
- Engine:
- 289 to 351W
- Material:
- Aluminum
- Combustion Chambers:
- 72 cc
- Intake Valve Diameter:
- 2.020 in.
- Exhaust Valve Diameter:
- 1.600 in.
- Intake Runners:
- 185.00 cc
- Exhaust Runners:
- 70.00 cc
- Port Style:
- Rectangular
- Cam Type Recommended:
- Hydraulic Roller
- Max Valve Lift:
- 0.600 in.
- Valve Spring OD:
- 1.290 in.
- Closed Spring Pressure:
- 140 lbs.
- Valve Spring Retainer Material:
- Steel
- Valve Material:
- Stainless Steel
- Notes:
- Stud mount rockers, with EGR.
- Quantity:
- Sold As Pair
