Air Flow Research Cylinder Head Assembly 1054; Eliminator Race Ready 210.00 cc Aluminum 65 cc for Chevy 262 to 400
$2,299.77
$2,592.45 On Sale
Save 11%
This item is not eligible for our Free Freight program because either this part type is excluded or its price is already at our lowest. However, it will still count toward the total when you purchase other items that do qualify for Free Freight.
See our shipping policy for more details.
Details
- 100% CNC Ported Combustion Chambers
- 100% CNC Ported Exhaust Ports
- 100% CNC Ported Intake Ports
- Competition 5-angle Valve Job
- 8mm Bead Lock Intake Valve, 2.080" x 5.000" Overall Valve Length
- 8mm Bead Lock Exhaust Valve, 1.600" x 5.030" Overall Valve Length
- PAC Racing Spring 1.550" OD Solid Roller Dual Valve Spring, 220 lbs on seat, .710" maximum lift,
- Max RPM 7200-7400
- Manley 10° Steel Retainers 1.500" O.D x 1.120" I.D x .705" I.D
- 10° Bead Lock Valve Keepers
- ARP 7/16" Rocker Studs
- Adjustable 5/16" Guide Plates
- Viton Valve Seals .600" O.D x .495" I.D
- Hardened Valve Spring I.D Locator 1.550" O.D x .780" I.D
- Ductile Iron Intake Valve Seats 2.200" O.D x 1.750" I.D x .375" Deep
- Ductile Iron Exhaust Valve Seats 1.696" O.D x 1.325" I.D x .305" Deep
- 8mm Bead Lock Intake Valve, 2.080" x 5.000" Overall Valve Length
- 8mm Bead Lock Exhaust Valve, 1.600" x 5.030" Overall Valve Length
- PAC Racing Spring 1.550" OD Solid Roller Dual Valve Spring, 220 lbs on seat, .710" maximum lift,
- Max RPM 7200-7400
- Manley 10° Steel Retainers 1.500" O.D x 1.120" I.D x .705" I.D
- 10° Bead Lock Valve Keepers
- ARP 7/16" Rocker Studs
- Adjustable 5/16" Guide Plates
- Viton Valve Seals .600" O.D x .495" I.D
- Hardened Valve Spring I.D Locator 1.550" O.D x .780" I.D
- Ductile Iron Intake Valve Seats 2.200" O.D x 1.750" I.D x .375" Deep
- Ductile Iron Exhaust Valve Seats 1.696" O.D x 1.325" I.D x .305" Deep
Product Description
AFRs 210cc Race Ready and Competition heads feature 100 percent CNC ported intake, exhaust & chambers, A356 aluminum castings and high quality components throughout. Recommended for race applications and aggressive street/ strip builds up to 400 cubic inches, operating up to 6500- 6800 RPM.
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Specifications
- Cylinder Head Assembly Series:
- Eliminator Race Ready
- Make:
- Chevy
- Engine:
- 262 to 400
- Material:
- Aluminum
- Combustion Chambers:
- 65 cc
- Intake Valve Diameter:
- 2.080 in.
- Exhaust Valve Diameter:
- 1.600 in.
- Spark Plug Angle:
- Angled
- Intake Runners:
- 210.00 cc
- Exhaust Runners:
- 80.00 cc
- Port Style:
- Rectangular
- Cam Type Recommended:
- Solid Roller
- Max Valve Lift:
- 0.710 in.
- Valve Spring OD:
- 1.550 in.
- Closed Spring Pressure:
- 220 lbs.
- Valve Spring Retainer Material:
- Steel
- Valve Material:
- Stainless Steel
- Notes:
- Raised 0.250 in. Exhaust
- Quantity:
- Sold As Pair
