Aeromotive Fuel System Fuel Pressure Regulator 13202; A2000 Carbureted 2 to 20 PSI Return Gasoline, Race Gas, E85, Alcohol Billet Aluminum
$221.77
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Details
- Adjustable from 2-20 PSI.
- Bypass design provides the ultimate, dynamic fuel delivery system. (Requires AN-10 return line)
- Fuel pressure rises on a 1:1 ratio when referencing boost.
- ORB-10 inlet and return ports.
- P/N 13202 provides (4) ORB-08 outlet ports.
Product Description
Dynamic flow and rock steady pressure make this regulator perfect for naturally aspirated or carbureted blow-through applications. The A2000 Bypass Regulator provides unmatched boost reference and high flow capacity. Compatible with any high volume electric or mechanical fuel pump. Adjustable from 2-20 PSI. Bypass design provides the ultimate, dynamic fuel delivery system. (Requires AN-10 return line.) Fuel pressure rises on a 1:1 ratio when referencing boost. ORB-10 inlet and return ports. P/N 13202 provides (4) ORB-08 outlet ports.?Note: High pressure, boost reference applications require high volume, high pressure fuel pumps. EFI capable, electric or mechanical pumps like the Aeromotive Pro-Series (P/N 11102), Eliminator (P/N 11104), or Belt Drive Fuel Pump (P/N 11105) are strongly recommended.WARNING: This product can expose you to chemicals, including chromium, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
WARNING: This product can expose you to chemicals, including chromium, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Specifications
- Fuel Pressure Regulator Series:
- A2000 Carbureted
- Regulator Pressure Range:
- 2 to 20 PSI
- Regulator Style:
- Return
- Compatible Fuels:
- Gasoline, Race Gas, E85, Alcohol
- Rebuildable:
- Yes
- Regulator Material:
- Billet Aluminum
- Regulator Spring Chamber Finish:
- Black
- Regulator Fuel Chamber Finish:
- Red
- Number of Inlet Ports:
- 1 Inlet
- Inlet Port Size:
- -10AN ORB Female
- Number of Outlet Ports:
- 4 Port
- Outlet Port Size:
- -08AN ORB Female
- Return Port Size:
- -10AN ORB Female
- Includes Pressure Port:
- No
- Includes Boost/Vacuum Reference Port:
- Yes
- Includes Pressure Gauge:
- No
- Includes Fittings:
- No
- Quantity:
- Sold As Each
