ACL Bearings Connecting Rod Bearing Set 4B1236H-STD; Race Series Performance Standard for 2007 to 2015 Mitsubishi EVO X 2.0L Turbo 4B11T
$42.98
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Details
- A blend of characteristics to provide high strength and excellent seizure resistance.
- No flash plating is applied to further improve bearing retention and maximise heat transfer.
- Improved bearing retention from higher radial contact pressure.
- Locks the bearing into the housing.
- More effective heat dissipation through improved thermal transfer.
- Definition: Gradual reduction in wall thickness between the crown and parting line.
- ACL Race Series performance engine bearings feature increased eccentricity to improve shape adaptation to compensate for bore distortion at high speed operation.
- Assists in the formation of hydrodynamic oil film.
- Accommodate larger fillet radii on performance crankshafts.
- More effective heat dissipation through improved thermal transfer.
- Definition: Gradual reduction in wall thickness between the crown and parting line.
- ACL Race Series performance engine bearings feature increased eccentricity to improve shape adaptation to compensate for bore distortion at high speed operation.
- Assists in the formation of hydrodynamic oil film.
- Accommodate larger fillet radii on performance crankshafts.
Product Description
ACL Race Series performance engine bearings are manufactured to exacting tolerances. Micron tolerance machining supported by precision measurement systems delivers consistent accuracy to key
characteristics like wall thickness and crush. This ensures reliable fit and helps maintain consistent clearances.
Specifications
- Engine Connecting Rod Bearing Set Model or Series:
- Race Series
- Year:
- 2007 to 2015
- Make:
- Mitsubishi
- Model:
- EVO X
- Engine:
- 2.0L Turbo 4B11T
- Bearing Undersize:
- Standard
- Usage:
- Performance
- Construction:
- Tri Metal
- Backing Layer Material:
- Steel
- Bearing Lining or Intermediate Material:
- Copper, Lead, Tin
- Overlay Material:
- Lead, Tin, Copper
- Coated:
- No
- Chamfered:
- Yes
- Bearing Width:
- 0.669 in.
- Standard Bearing Thickness (Without O/S):
- 0.059 in.
- Standard Crank Pin Diameter (Without O/S):
- 2.045 in.
- Standard Housing Diameter (Without O/S):
- 2.165 in.
- Quantity:
- Sold As Set (4/pkg)
