Flo-Tek Cylinder Head Assembly 1200-HRAC-505A; 200cc Aluminum 64cc for Chevy 262-400

View the full image
View the full image
View the full image
View the full image
View the full image
View the full image

Price:	$589.00

Brand:

Flo-Tek

SKU:

FTK1200-HRAC-505A

UPC:

850134007242

Box Dimensions:

22.5 × 8.4 × 7 in

Box Weight:

29 lb

Horizontal Tabs

Description & Specs

Make:

Chevy

Engine:

262-400

Port Style:

Rectangular Port

Combustion Chambers:

64cc

Intake Valve Diameter:

2.020 in.

Exhaust Valve Diameter:

1.600 in.

Spark Plug Angle:

Angled

Material:

Aluminum

Intake Runners:

200cc

Exhaust Runners:

78cc

Cam Type Recommended:

Hydraulic Roller

Max Valve Lift:

0.650 in.

Valve Spring OD:

1.460 in.

Closed Spring Pressure:

142 lbs at 1.800 in.

Open Spring Pressure:

400 lbs at 1.150 in.

Spring Rate:

396.9 lbs/in

Coil Bind:

1.040 in.

Valve Spring Retainer Material:

Chromoly

Quantity:

Sold As Each
